| System Specifications. |
|
| Ángulo de visión (°) |
Horizontal field of view: 57.6° to 2.5° (wide-tele), Vertical field of view: 34.4° to 1.4° (wide-tele), Diagonal field of view: 64.5° to 2.9° (wide-tele) |
| Formato de audio |
G.711/G.722.1/G.726/MP2L2/PCM |
| Sensor de imagen |
1/2.8" progressive scan CMOS |
| Indicadores |
Power |
| Filtro de corte IR |
Sí |
| Alcance IR |
Up to 100 meter |
| Lente |
4.8 mm to 120 mm, F1.6 |
| Iluminación mínima (lux) |
Color: 0.005 Lux @ (F1.6, AGC ON); B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Monte |
Montaje en pared |
| Gama Pan (Giratoria) |
360°,Pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s |
| Configuración de puertos |
RJ45/DI/Power |
| Consumo de energía |
Max. 24 W, including max. 9 W for supplement light |
| Alimentación |
VDC 12V /2A |
| Fuente de alimentación incluida |
Sí |
| Resolución |
Main Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream:
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream:
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
|
| Tiempo de obturación |
1s to 1/30,000 s |
| Estándar |
IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| Supported storage capacity. |
256 GB |
| Alcance de inclinación |
-15° to 90° (auto flip), Tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s |
| Formato de vídeo |
H.265/H.264/MJPEG |
| Resistencia a la intemperie |
IP66 |
| Others. |
|
| Aprobación y conformidad |
CE/FCC/UL,/IP66/RoHS
UL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
TVS 6000V lightning protection, surge protection and voltage
transient protection |
| Compatibilidad |
Onvif Version 19.12, Profile S, Profile G, Profile T
Simultaneous Live View: Up to 20 channels
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address) |
| Humedad de funcionamiento |
0% HR ~ 90% HR |
| Temperatura de funcionamiento |
-30°C ~ 65°C |
| Navegadores compatibles |
Edge |
| Sistemas operativos compatibles |
Windows 10 |
| Contenido del paquete |
FCS-4051
Screw Kit
Power adapter
Quick Installation Guide
Resource CD (User Manual, Utility, QIG) |
