| System Specifications. |
|
| Angle of view (°). |
Horizontal FOV 106° to 32°, Vertical FOV 56° to 18°, Diagonal FOV 127° to 37° |
| Audio format. |
G.711/G.722.1/G.726/MP2L2/PCM |
| Image sensor. |
1/2.4" Progressive Scan CMOS |
| Indicators. |
Power
Link/act |
| IR cut filter. |
Yes |
| IR range. |
60 Meters |
| Lens. |
Varifocal Motorized Lens, 2.8 to 12 mm |
| Minimum illumination (lux). |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Mount. |
Wall mount |
| Port Configuration. |
RJ-45,Power plug ,DI/DO |
| Power consumption. |
12 VDC ± 25%, 1.08 A, max. 13 W, Ø5.5 mm coaxial power plug
PoE: 802.3at, Class 4, 42.5 V to 57 V, 0.36 A to 0.27 A, max. 15 W |
| Power supply. |
12 VDC ± 25%, PoE: 802.3at |
| Power supply included. |
No |
| Resolution. |
Main Stream
50 Hz: 20 fps (3200 × 1800)
25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (3200 × 1800)
30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (1280 x 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 x 720, 640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
|
| Shutter time. |
1/3 s to 1/100,000 s |
| Standard. |
IEEE 802.3 10-BASE-T, Ethernet
IEEE 802.3u 100-BASE-TX, Fast Ethernet
IEEE 802.3af Power over Ethernet (PoE)
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, SRTP, SFTP |
| Supported storage capacity. |
256 GB |
| Video format. |
H.265/H.264/MJPEG |
| Weatherproof rating. |
IP67 |
