FCS-5095, GEMINI ZOOM IP CAMERA, 8-MP, H.265, 802.3AT, POE, IR LEDS, INDOOR/OUTDOOR, TWO-WAY AUDIO

Model Number.

FCS-5095

SKU

57303607201

8-Megapixehigh-definition resolution

Built-in infrared LEDs for night viewing up to 60m

Dual power support: 12V DC/PoE (IEEE 802.3at)

Video compression: H.264, H.265, MJPEG

Weatherproof IP67-rated housing

Vandal-proof IK10-rated housing

Supports 4.3X optical zoom

Details

The LevelOne FCS-5095 is a fixed-position outdoor camera offering an ultra-reliable, cost-effective solution for outdoor IP surveillance networks, and is rated at IP67 to operate within rain, extreme heat, snow, dust and humid conditions. Offering clear, sharp imagery with 8-Megapixel resolution and the versatility of 802.3at standard PoE to transfer power and data via a single Cat.5 cable, the LevelOne FCS-5095 should be an essential part of any security deployment that requires smart, reliable outdoor cameras.

Specifications

More Information
Logistics Data.
Harmonized System (HS) code.	852589
Customs product code (TARIC).	8525890000
Features 1.
Features.	Basic Event: Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception Smart Event: Face detection,Line crossing detection, intrusion detection (support alarm triggered by specified target types (human and vehicle)) Linkage: Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger recording,trigger capture
Miscellaneous.
2-way audio.	Yes
DI/DO.	Yes
IR LED for night vision.	Yes
Max. Resolution.	8 Megapixels
Resistance.	Weatherproof
IP Camera series.	GEMINI
Camera Type.	Bullet
Zoom type.	Motorization
PoE Supported.	Yes
Physical Specifications.
Dimensions (W x D x H).	385x190x180
Product weight (kg).	1.385
System Specifications.
Angle of view (°).	FOV 108° to 30°, vertical FOV 56° to 17°, diagonal FOV 131° to 35°
Audio format.	G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
Image sensor.	1/2.8" Progressive Scan CMOS
Indicators.	Powe /Link Act
IR cut filter.	Yes
IR range.	Up to 60 Meter
Lens.	Motorized lens, 2.8 to 12 mm
Minimum illumination (lux).	Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR
Mount.	Wall mount
Port Configuration.	RJ-45, DI/DO (terminal block), Audio In/Out (terminal block)
Power consumption.	12 VDC ± 25%, 1.08 A, max. 13 W,Ø5.5 mm coaxial power plug,reverse polarity protection, PoE: 802.3at, Class 4, 42.5 V to 57 V, 0.36 A to 0.27 A, max. 15 W
Power supply included.	No
Resolution.	Main Stream 50 Hz: 20 fps (3840 × 2160) 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720) 60 Hz: 20 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)
Shutter time.	1/3 s to 1/100,000 s
Standard.	TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
Supported storage capacity.	256 GB
Video format.	H.265/H.264/MJPEG
Weatherproof rating.	IP67
Others.
Approval and Compliance.	CE/FCC/UL
Compatibility.	Onvif
Operating humidity.	5% RH ~ 95% RH
Operating temperature.	-30°C ~ 60°C
Supported browsers.	Plug-in required live view: IE 10, IE 11,Edge Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Compatible operating systems.	Ooption accessory Mounting Kit : CAS-7303 Pole Mount CAS-7307 Corner mount CAS-7311 Junction Box CAS-7312 Power intake box
Storage humidity.	5% RH ~ 95% RH
Storage temperature.	-30°C ~ 70°C
Package Contents.	Screw Kit QIG
General.
Color.	White
EAN.	4015867228654
Model Number.	FCS-5095
