| System Specifications. |
|
| Angle of view (°). |
Horizontal FOV 107°, Vertical FOV 57°, Diagonal FOV 128° |
| Audio format. |
G.711/G.722.1/G.726/MP2L2/PCM |
| Image sensor. |
1/2.4" Progressive Scan CMOS |
| Indicators. |
Power |
| IR cut filter. |
Yes |
| IR range. |
Up to 30 meter |
| Lens. |
Fixed 2.8mm @F1.6 |
| Minimum illumination (lux). |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| Mount. |
Ceiling mount |
| Port Configuration. |
Power( Ø5.5 mm coaxial power plug)/RJ-45/DIDO Terminal block ,12 VDC, 30 mA /Line IN /OUT (Terminal block), Input_(4.7 KΩ, 3.3 Vpp), Output (3.3 Vpp, 100 Ω) |
| Power consumption. |
12 VDC, 0.6 A, max. 7.5W
PoE: (802.3af, 36V to 57V), 0.3 A to 0.2 A, max. 9W |
| Power supply included. |
No |
| Resolution. |
Main Stream
50 Hz: 20 fps (3200 × 1800)
25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (3200 × 1800)
30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
Sub Stream
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360)
Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360) |
| Shutter time. |
1/3 s to 1/100,000 s |
| Standard. |
IEEE 802.3 10-BASE-T, Ethernet
IEEE 802.3u 100-BASE-TX, Fast Ethernet
IEEE 802.3af Power over Ethernet (PoE)
IEEE 802.1X Network Access Control
TCP(IPv6/v4), UDP, HTTP, HTTPS, DHCP, PPPoE, RTP, RTSP, DNS, DDNS, NTP, ICMP, ARP, IGMP,
SMTP,FTP,SAMBA UPnP, SNMP, Bonjour |
| Supported storage capacity. |
128 GB |
| Video format. |
Main stream: H.265/H.264
Sub-stream: H.265/H.264/MJPEG |
| Weatherproof rating. |
IP-67 |
